D-Link 5-Port Multi-Gigabit Unmanaged Switch - 5.0 Ports - 2.5 Gigabit Ethernet, Gigabit Ethernet - 2.5GBase-T, 10/100/1000Base-T - 2 Layer Supported - 4.92 W Power Consumption - Twisted Pair
$118.81
SKU: AG7358
MFG #: DMS-105
Guarantee Safe
Checkout
- Description
- Specifications
The DMS-105 5-Port Multi-Gigabit Unmanaged Switch is ideally suited for Small Office Home Office (SOHO) environments. With a durable design, silent operation, and plug-and-play functionality, the DMS-105 switch can be easily set up and be placed in almost any location where network connectivity is required. Support for IEEE 802.3az Energy-Efficient Ethernet (EEE), 802.1p Quality of Service (QoS), and multi-Gigabit Ethernet connection speeds provide advanced features in a compact package.
Integrated Networking
The DMS-105 switch uses auto-sensing ports, providing a small workgroup to flexibly connect Ethernet, Fast Ethernet, Gigabit and 2.5 Gigabit devices to create an integrated network. These ports detect the network speed via auto-negotiation allowing you to get the maximum speed possible for each device connected to your network.
Simplified Installation
All of the ports on the DMS-105 switch supports automatic MDI/MDIX crossover, eliminating the need for crossover cables. Each port can be plugged in directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables. In addition, the DMS-105 switch features multiple front, easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 5.0 ports
Network & Communication
| Compliant Standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Features | Auto-negotiation, Auto-sensing per device, Auto-uplink (auto MDI/MDI-X), D-Link Green Technology, Energy-Efficient Ethernet (EEE), Fanless, Flow control, IGMP snooping, Link Fault Detection, Metal housing, Quality of Service (QoS), SOHO (Small Office/Home Office), Store and forward |
| Form Factor (Hubs & Switches) | Desktop, Wall-mountable |
| MAC Address Table Size | 4K entries |
| Manageable | No |
| Ports | 5 |
| Product Type | Switch |
| Status Indicators | Link/activity, Power |
| Subcategory | Network hubs and switches |
| Switching Type | 2.5 Gigabit Ethernet |
Connectivity
| Interface Provided | 5 x 10/100/1000/2.5G RJ-45 |
| Port Quantity | 5 |
| Port Type | 10/100/1000/2.5G |
Power
| Output Current | 1 ampere |
| Provided Voltage | 12 volt |
Technical Information
| Humidity Range Storage | 5 - 90% RH |
| Max Operating Temperature | 104 degree Fahrenheit |
| Max Storage Temperature | 158 degree Fahrenheit |
| Min Operating Temperature | 32 degree Fahrenheit |
| Min Storage Temperature | 14 degree Fahrenheit |
| MTBF | 765,190.81 Hours |
| Operating Humidity | 10 - 90% RH |
Product Information
| Capacity | Packet buffer size: 8.1 MB |
| Device Type | External power adapter |
| Packaged Quantity | 1 |
| Performance | Packet forwarding rate: 18.6 Mpps, Switching capacity: 25 Gbps |
Dimensions & Weight
| Height | 1.1 inch |
| Weight | 8.42 ounce |
| Width | 4 inch |
| Depth | 3.2 inch |
Physical Characteristics
| Color Category | Black |
Certifications & Listings
| Compliant Standards | BSMI, BSMI Class B, FCC Class B certified, IC Class B, LVD, NDAA, Plug and Play, RCM Class B, RoHS, VCCI Class B |
| ENERGY STAR Certified | No |
| EPEAT Compliant | No |
| TCO Certified | No |
Service & Support
| Service & Support Details | Limited warranty - lifetime |
| Limited Warranty | Limited Lifetime |
